Nearly all crash barrier accidents happen to authorised gate users, posing significant user peril and owner liability exposure. StrongArm M30 or M50 mitigate this fact by employing many standard safety benefits not offered by competitor operators. These products take barrier arms to the extreme. These machines stop a 15.000 lb truck driving 30 mph (and 50 mph respectively) in its tracks. While they protect many key assets, they also protect against accidental injury and death. The unique dual arm design prevents a large truck or a small passenger vehicle from breaching the security perimeter. Full 90º opening prevents tall vehicles from clipping the arm. Its hydraulics & controls are securely housed in pivot post. No need for expensive trenching and vulnerable external enclosure.
Furthermore, it has highly visible LED lighting that protects against accidental impact. They feature a fast arm speed of 6-8 seconds, depending on arm length. This reduces traffic backup by minimising gate open time.
CERTIFICATIONS

TECHNICAL INFORMATION
Model | StrongArm Crash M30 | StrongArm Crash M50 |
Certification | ASTM F2656-07 M30-P1 | ASTM F2656-07 M50-P2 |
Clear opening width | 12 to 24 ft. in 2 ft. increments (366 to 732 cm in 61 cm increments). Call for custom arm length | 12 to 24 ft. in 2 ft. increments (366 to 732 cm in 61 cm increments). Call for custom arm length |
Operating time | 6 to 8 seconds depending on arm length | 6 to 8 seconds depending on arm length |
Emergency fast time | 5 to 7 seconds depending on arm length | 5 to 7 seconds depending on arm length |
Duty cycle | 100 cycles/hr, option for continuous duty | 100 cycles/hr, option for continuous duty |
